Deep Groove Ball Bearing
Our company specializes in manufacturing various types of ball bearings, utilizing high-quality chrome steel AISI52100 (100CR6/GCr15) . Our production line features fully automated lathes, M7650 double face grinders, M10100 centerless grinders, 3M6280 super outer ring grinding machines, 3MZ201C fully automated bore of inner ring grinding machine, 3MZ131C fully automated groove of inner ring grinding machine, ZDJY-8 automatic super grinding machines.We have a one-stop automated assembly line for riveting, greasing, covering and oiling of finished products. Our products are characterized by high precision, stable performance, smooth operation, low friction, and long life. They are widely used in motors, washing machines, water pumps, electric fans, automated equipment, textile machinery, hardware tools, and transmission systems. The product range is comprehensive, with minimum outer diameters starting from 6mm and maximum outer diameters up to 120mm.
Detailed Information
Production process：
| Bearing no. inside | diameter(mm) outside | diameter(mm) | width (mm) |
|
|
d | D | B |
| 6000 | 10 | 26 | 8 |
| 6001 | 12 | 28 | 8 |
| 6002 | 15 | 32 | 9 |
| 6003 | 17 | 35 | 10 |
| 6004 | 20 | 42 | 12 |
| 6005 | 25 | 47 | 12 |
| 6006 | 30 | 55 | 13 |
| 6007 | 35 | 62 | 14 |
| 6008 | 40 | 68 | 15 |
| 6009 | 45 | 75 | 16 |
| 6010 | 50 | 80 | 16 |
| 6200 | 10 | 30 | 9 |
| 6201 | 12 | 32 | 10 |
| 6202 | 15 | 35 | 11 |
| 6203 | 17 | 40 | 12 |
| 6204 | 20 | 47 | 14 |
| 6205 | 25 | 52 | 15 |
| 6206 | 30 | 62 | 16 |
| 6207 | 35 | 72 | 17 |
| 6208 | 40 | 80 | 18 |
| 6209 | 45 | 85 | 19 |
| 6210 | 50 | 90 | 20 |
| 6300 | 10 | 35 | 11 |
| 6301 | 12 | 37 | 12 |
| 6302 | 15 | 42 | 13 |
| 6303 | 17 | 47 | 14 |
| 6304 | 20 | 52 | 15 |
| 6305 | 25 | 62 | 17 |
| 6306 | 30 | 72 | 19 |
| 6307 | 35 | 80 | 21 |
| 6308 | 40 | 90 | 23 |
| 6309 | 45 | 100 | 25 |
| 6310 | 50 | 110 | 27 |
| 16001 | 12 | 28 | 7 |
| 16002 | 15 | 32 | 8 |
| 16003 | 17 | 35 | 8 |
| 16004 | 20 | 42 | 8 |
| 16005 | 25 | 47 | 8 |
| 16006 | 30 | 55 | 9 |
| 16007 | 35 | 62 | 9 |
| 16008 | 40 | 68 | 9 |
| 16009 | 45 | 75 | 10 |
| 16010 | 50 | 80 | 10 |
